CNC Drilling and Routing Machining Centers DRILLTEQ V-310

CNC Drilling and Routing Machining Centers DRILLTEQ V-310

Maximum cabinet processing. Minimum space requirements. A space-saving miracle that requires just 11 m² of floor space.

The smart concept behind the DRILLTEQ V-310 offers as much functionality as possible in as small a space as possible. It makes optimum use of its 11 m², offering more drilling, more grooving and more trimming than any other machine in this design class. It is even possible to process doors, as well as every type of connector used in furniture construction. Optimize your workpiece handling and tool change handling with intelliGuide LED operator assistance, and look forward to ergonomic processing thanks to the swiveling control unit and the height-adjustable monitor.

Highlights

Split-head drilling gear to enable simultaneous processing of mirror-image workpieces.

Extensive equipment — up to 45 drilling spindles, 2 groove saws.

Whether classic trimming and drilling or the production of pockets, there are no limits to the choice of furniture connectors.

Whether classic trimming and drilling or the production of pockets, there are no limits to the choice of furniture connectors.

Energy-efficient processing — the vacuum-free clamping system impresses with its lack of setup times

Energy-efficient processing — the vacuum-free clamping system impresses with its lack of setup times

Features

  • A doweling unit and a C axis with unit interface are available.

  • 5° gravity-based tilting for easier workpiece handling

  • Foot switching strip for easy workpiece clamping

  • Plausibility check and workpiece measuring to safeguard processes

  • safeScan — safety concept for optimum and safe interaction between man and machine

  • Barcode scanner to quickly access and read programs and requirements

  • Ergonomic workflows — intuitive operation with fewer manual steps thanks to a small radius of movement due to the machine's compact construction

Technical Data

Workpiece length [mm]

200 – 3,050

Workpiece width [mm]

50 – 1,250

Workpiece thickness [mm]

8 – 80

Total machine weight [kg]

ca. 3,600

Installation dimensions L x W x H [mm]

5,300 x 2,260 x 2,160

Automation & Further Functionality

To process the 6th side, the workpieces are now automatically fed back into the machine without any additional manual intervention. It’s now a fully automated solution for complete part processing.

Workpiece returning with reverse function

The workpiece return system is the perfect addition. The 6-sided processing runs automatically in a single flow and offers complete processing of the workpieces after a one-time loading. The material flow is automated and the process becomes more efficient. Manual part handling is reduced to a minimum. Downtimes are minimized and output is increased.

FEEDBOT D-310

Safe, precise, automatic handling of workpieces for more efficient production

Software

Here's how your colleagues produce

Videos

Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


» Privacy Policy

DRILLTEQ V-310 Vertical CNC Processing Center

The space-saving miracle in CNC processing.

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    HOMAG DRILLTEQ V-310 | Automatic material handling with FEEDBOT D-310

    A CNC processing center with robot support forms one of the smallest possible cells of the furniture production.

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    DRILLTEQ V-310 vertical CNC processing center

    Clamex processing in the edge - Middle wall

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    DRILLTEQ V-310 vertical CNC processing center

    LED assistance system intelliGuide – Workpiece positioning

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    DRILLTEQ V-310 vertical CNC processing center

    intelliGuide LED assistance system - Tool changer

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    DRILLTEQ V-310 vertical CNC processing center

    Processing cabinet door with pot hinge drilling

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    DRILLTEQ V-310 vertical CNC processing center

    Processing narrow part - drawer front piece

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    DRILLTEQ V-310 vertical CNC processing center

    Room Door Processing

  • Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.


    » Privacy Policy

    CNC Drilling and Routing Centers DRILLTEQ V-310

    Workpiece return system with reversing function
