Comprehensive equipment standard
The single-sided EDGETEQ S-500 offer precise gluing and perfect post-processing of edges. PUR and airTec can be used if required. The selectable feed rate of 16-20, 25 (30) m/min enables demand-based productivity for woodworking shops and for businesses with higher performance requirements. Automation and further functionality can be added on an individual basis for these edge banding machines.
Highlights
Intuitive operation with the powerTouch control system. Control machine functions directly using the multi-touch, widescreen monitor. The ergonomic design, as well as numerous help and assistant functions, simplify operation significantly.
Controlled chip collection. The chips are suctioned off in the interior and fed to the extraction hood in a targeted manner. Reduced wear and tear and lower service costs increase profitability and service life. The reduced suction speed lowers energy consumption and costs.
Trimming quality of the highest standard with the profile trimming unit FK30. The motion sequence is performed with linear motors. The high accelerations of the linear motors when rounding the edge enable the best-possible processing quality.
Images
-
![]()
PUR gluing with EDGETEQ S-500 -
![]()
Zero-joint-technology with airTec -
![]()
Snipping unit PK25 -
![]()
Feinfräsaggregat PF21: Zum Fräsen von Fase und Radien mit optimierter Späneabsaugung und automatischem Wechsel von 2 Radien und Fase. -
![]()
Profile trimming unit MF60 Servotrim -
![]()
Grooving unit SF21
Features
-
woodCommander5.1: Software for quick selection of the processing programs and the edge material
-
Processing of rolls of material up to 3 mm, of strips up to 12 mm alternative of solid strips up to 20 mm
-
The finishing unit at the outfeed removes any glue residue and ensures the edges grip well
-
Zero-joint technology with HOMAG airTec can be used
-
Automatic setup for different profiles
-
NEW: With the narrow part package, particularly narrow workpieces of up to 40 mm can be processed precisely
-
Low energy costs plus material savings with ecoPlus
Technical Data
EDGETEQ S-500 | |
|---|---|
| Feed speed adjustable [m/min] | 16 – 20 (25) |
Workpiece width [mm] * with workpiece thickness 8 - 22 mm |
60 |
| Workpiece thickness [mm] | 8 – 60 / 12 – 60 |
| Edge thickness, coils [mm] | 0.3 – 3 |
| Edge thickness, strips / solid wood strips [mm] | 0.3 – 12 (20) |
* dependent on the workpiece thickness
Software
-
![]()
Edgeband Management Set: The edgeband assistant
The edge material and all related information at a glance
Clear management and unique identification of edges in the rack (incl. residual lengths)
Reduced setup times thanks to faster edge changes
-
![]()
materialManager
All material data and stocks managed clearly in just one digital application
Central material management in the company
Integrated use of material data
Here's how your colleagues produce
Videos
Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.
» Privacy Policy
HOMAG EDGETEQ S-500 mit LOOPTEQ O-600
Höhere Produktivität für Ihre Kantenanleimmaschine
-
![]()
Please confirm that when you use YouTube, data such as your IP address, browser identifier and similar may be transmitted to Google.
» Privacy PolicyDas Edge Data Package im Einsatz
Das Edge Data Package im Einsatz bei der Schreinerei Lechner
Brochures
Product Comparison
Edge banding machine
|
|
|
|
| |
|---|---|---|---|---|---|
| EDGETEQ S-200 | EDGETEQ S-240 | EDGETEQ S-300 | EDGETEQ S-380 | profiLine | EDGETEQ S-500 Optimat | profiLine | |
| Feed rate adjustable [m/min] | 8-11 | 11 | 8-14 | 8-20 | 16-20 (25) |
| Workpiece width min. [mm] * in case of thickness 8-22 mm | 70 | 70 | 70 | 70 | 60 |
| Workpiece thickness [mm] | 8-60 | 8-60 | 8-60 | 8-60 | 8-60 |
| Edge thickness coils [mm] | 0,3-3 | 0,3-3 | 0,3-3 | 0,3-3 | 0,3-3 |
| Edge thickness strips / solid strips [mm] | 0,3-3 | 0,4-6 | 0,4-8 | 0,4-15 | 0,3-12 (20) |
